Low Rider Cart – 1050 x 1400 mm
Low Rider Cart – 1050 x 1400 mm
Low Rider Cart – 1050 x 1400 mm
Low Rider Cart – 1050 x 1400 mm
Q-100-1324

Low Rider Cart – 1050 x 1400 mm

This low rider pallet cart is designed to transport pallets, boxes or containers.

Technical specifications

Category: Flat Deck

Industry: Automotive, Defense Equipment, Distribution, Industrial Machinery, Tier One Suppliers, Wind & Energy

Width: 1050 mm

Length: 1400 mm

Load capacity: 120 kg

Transportation method: Manual, Tugger

Caster size: 125 mm

Caster Type: Polyurethane

More info

This low rider cart can be used to transport pallets, containers, boxes or loose components. It is designed to have the platform at a low height from the floor to be able to use a specific type of lifting device. This cart is equipped with polyurethane casters and a foot release tow bar.

Parts included
FlexBeam™ 1050 mm FE 8 Q-001-1402
FlexBeam™ 1260 mm FE 2 Q-001-1500
Caster Polyurethane 125 mm 80 x 60 Swivel 2 Q-004-1220
Caster Polyure. 125 mm, 80 x 60, Fixed 2 Q-004-1221
Triangle Joint 4 Q-005-0483
Extended caster attachment – 180 x 160 (Welded) 4 Q-005-0881
Collet 32 x 15 x M10 Threads 12 Q-005-0924
31 mm Collet 2 Q-005-1008
Spring Cover Plate 1 Q-005-1025
64 mm FlexBeam™ Collet 12 Q-005-1426
Hat Profile – 1260 x 38 mm 3 Q-005-2331
M8 x 20 mm Hex Head Fully Threaded 16 Q-006-1019
M14 x 60 mm Hex Head 2 Q-006-1036
Locking Nut M14 2 Q-006-1039
M10 x 25 mm Hex Head 8 Q-006-1041
Locking Nut M10 77 Q-006-1042
M10 x 95 mm Hex Head 3 Q-006-1088
M10 x 70 mm Countersunk 1 Q-006-1112
M10 x 90 mm Hex Head 23 Q-006-1132
Locking Nut M8 16 Q-006-1181
M10 x 50 mm Hex Head Fully Threaded 2 Q-006-1343
Self Tapping Screw M6 Torx H60 x 16 60 Q-006-1384
M10 x 16 mm Low Allen Head 20 Q-006-1409
M10 x 25 mm Extra Low Head Allen 44 Q-006-1410
Spring 1.5 x 15yd x 70 1 Q-012-1141
Top Plate w. edge – 1050 x 1260 mm 1 Q-016-0690
Countersunk Towing Lock Pin – 25 mm 1 Q-017-0010
Foot Release Locking Lip 1 Q-017-0024
Heavy Duty Tow Hinge – Narrow 1 Q-017-0087
Tow Hole 28 mm – Symmetrical 1 Q-017-1066
