Pallet Tugger Cart – 2450 x 1750 mm
Pallet Tugger Cart – 2450 x 1750 mm
Pallet Tugger Cart – 2450 x 1750 mm
Pallet Tugger Cart – 2450 x 1750 mm
Q-100-0427

Pallet Tugger Cart – 2450 x 1750 mm

Tuggable low rider flatbed cart. Equipped with a tow bar, floor brake, handlebar and six polyurethane casters.

Technical specifications

Category: Flat Deck

Industry: Automotive, Defense Equipment, Distribution, Industrial Machinery, Tier One Suppliers, Wind & Energy

Width: 1750 mm

Length: 2450 mm

Load capacity: 750 kg

Transportation method: Manual, Tugger

Caster size: 125 mm

Caster Type: Polyurethane

More info

Tuggable low rider flatbed pallet cart, great for the transportation of larger pallets and containers or several smaller ones. The cart is equipped with a tow bar, floor brake, handlebar and six high quality polyurethane casters which give the cart excellent tracking properties and silent movement when connected in a train.

Parts included
FlexBeam™ – 1330 mm 2 Q-001-1298
FlexBeam™ 1050 mm 4 Q-001-1302
FlexBeam™ 770 mm 4 Q-001-1306
FlexBeam™ 630 mm 2 Q-001-1308
FlexBeam™ 1050 mm FE 2 Q-001-1402
FlexBeam™ 1400 mm FE 2 Q-001-1502
FlexBeam™ 1610 mm FE 6 Q-001-1505
FlexPlate™ 19 Q-002-1001
Flexplate™ M10 14 Q-002-1162
Floor lock COLSON – 4" x 4–1/2" – 125 – 150 mm 1 Q-004-0031
Caster distance plate – 5 mm 4 Q-004-0038
125 mm Swivel Caster 6 Q-004-1363
125 mm Fixed Caster 2 Q-004-1365
31 mm Collet 2 Q-005-1008
Old part: Spring for Tow Bar 2 Q-005-1012
Spring Cover Plate 1 Q-005-1025
Wheel Attachment Box 8 Q-005-1079
Angled Corner Plate 4 Q-005-1098
Reinforcement Plate – 770 mm 2 Q-005-1112
64 mm FlexBeam™ Collet 16 Q-005-1426
M20 x 500 mm Hex Head 1 Q-006-1016
M14 x 60 mm Hex Head 2 Q-006-1036
Locking Nut M14 2 Q-006-1039
M10 x 25 mm Hex Head 25 Q-006-1041
Locking Nut M10 72 Q-006-1042
M8 x 20 mm MELC6S 10.9 Allen Head 8 Q-006-1044
M10 x 95 mm Hex Head 2 Q-006-1088
M10 x 70 mm Countersunk 1 Q-006-1112
M10 x 90 mm Hex Head 8 Q-006-1132
M10 x 90 mm Countersunk MF6S 12 Q-006-1135
Locking Nut M8 32 Q-006-1181
Hex Head – M10 x 40 1 Q-006-1208
M10 x 100 mm Hex Head 2 Q-006-1302
M10 x 50 mm Hex Head Fully Threaded 2 Q-006-1343
M10 x 90 mm Extra Low Head 15 Q-006-1381
Self Tapping Screw M6 Torx H60 x 16 122 Q-006-1384
M6 x 20 Countersunk Self Tapping Screw 166 Q-006-1385
M20 Locking Nut 1 Q-006-1405
M10 x 25 mm Extra Low Head Allen 4 Q-006-1410
Spring 1.5 x 15yd x 70 1 Q-012-1141
Low Rider Floor Brake Plate 1 Q-015-0019
Handlebar Attachment EUR 2 Q-015-0026
Tube for Handlebar EUR 1 Q-015-0033
Top plate – 1750 x 2450 mm 4 Q-016-0223
Countersunk Towing Lock Pin – 25 mm 1 Q-017-0010
EUR Modular Tow Bar Foot Release VKR – 670 mm 1 Q-017-0016
Foot Release Locking Lip 1 Q-017-0024
Locking lip attachment 1 Q-017-1043
Tow Hole 28 mm – Symmetrical 1 Q-017-1066
Tow Attachment to Beam 1 Q-017-1080
Tow Hinge 1 Q-017-1083
