Euro Pallet Cart - 840 x 1260 mm
Euro Pallet Cart - 840 x 1260 mm
Euro Pallet Cart - 840 x 1260 mm
Euro Pallet Cart - 840 x 1260 mm
Q-100-1656

Euro Pallet Cart - 840 x 1260 mm

EUR pallet cart equipped with corner pallet guides and six polyurethane/nylon casters.

Technical specifications

Category: Standard

Industry: Automotive, Commercial Vehicles, Tier One Suppliers

Width: 33 inch

Length: 50 inch

Load capacity: 2205 lbs

Transportation method: LiftRunner Frames, Manual

Caster size: 5 inch

Caster Type: Gray

Type of Load: Pallets and Containers

More info

This standard pallet cart can be used to transport pallets/containers. It is equipped with corner pallet guides and six polyurethane/nylon casters.

Parts included
FlexPlate™ 8 Q-002-1001
Swivel Caster - 125 mm 2 Q-004-1363
125 mm Swivel Caster with Brake 2 Q-004-1364
Fixed Caster - 125 mm 2 Q-004-1365
Spring Threaded Tube Connectors 12 Q-005-0469
Pallet Guide Corner Plate 4 Q-005-1096
64 mm FlexBeam™ Collet 12 Q-005-1426
Wheel Attachment - 80 x 60 mm 2 Q-005-1722
Locking Nut M10 28 Q-006-1042
Locking Nut M8 24 Q-006-1181
M8 x 16 mm Countersunk 16 Q-006-1214
Countersunk - M8 x 20 8 Q-006-1282
Extra Low Head - M10 x 90 mm 24 Q-006-1381
Self Tapping Screw M6 Torx H60 x 16 56 Q-006-1384
Extra Low Head Allen - M10 x 25 mm 16 Q-006-1410
FlexBeam™ - 1190 mm 4 Q-020-1190
