Flat Deck Cart 1260 x 630 mm
Flat Deck Cart 1260 x 630 mm
Flat Deck Cart 1260 x 630 mm
Flat Deck Cart 1260 x 630 mm
Flat Deck Cart 1260 x 630 mm
Q-100-0190

Flat Deck Cart 1260 x 630 mm

Standard push cart for transporting pallets and containers.

Technical specifications

Category: Flat Deck

Industry: Appliances & Electronics, Distribution, Medical Equipment

Width: 25 inch

Length: 50 inch

Load capacity: 3307 lbs

Transportation method: Manual

Caster size: 8 inch

Caster Type: Nylon

More info

This pallet cart with added top plate is used to transport heavy containers. It has adouble bend for containers to make it more robust. It also comes equipped with an ergonomic handlebar for easie manual transportation. It comes with four polyamide casters, two of which are fixed for easier movability.

Parts included
FlexBeam™ 1190 mm 4 Q-001-1300
FlexBeam™ 630 mm FE 2 Q-001-1408
FlexBeam™ 490 mm FE 4 Q-001-1410
FlexPlate™ 8 Q-002-1001
Wheel Attachment - 105 x 77,5 mm 4 Q-004-1065
Polyamide Caster 200 mm without Brake 2 Q-004-1352
Polyamide Caster 200 mm Fixed 2 Q-004-1354
Floor Brake LTL - 200 mm 1 Q-004-1359
L Bracket Joint 4 Q-005-0031
64 mm FlexBeam™ Collet 30 Q-005-1426
Pallet Guide Heavy - 5 mm 4 Q-005-1645
Locking Nut M10 54 Q-006-1042
Washer M10 16 Q-006-1043
Hex Head - M10 x 95 mm 2 Q-006-1088
Hex Head - M10 x 90 mm 26 Q-006-1132
Hex Head - M10 x 30 mm 6 Q-006-1161
Extra Low Head - M10 x 90 mm 18 Q-006-1381
Self Tapping Screw M6 Torx H60 x 16 48 Q-006-1384
Countersunk Self Tapping Screw - M6 x 20 56 Q-006-1385
Hex Head Fully Threaded - M10 x 60 mm 2 Q-006-1502
Handlebar / Floor Brake Attachment US 1 Q-015-0029
Handlebar Attachment US 1 Q-015-0031
Tube for handle with bent top - 560 mm 1 Q-015-0042
Top Plate - 1260 x 630 mm 1 Q-016-0117
