Kit cart - 1190 x 980 mm
Kit cart - 1190 x 980 mm
Kit cart - 1190 x 980 mm
Kit cart - 1190 x 980 mm
Q-100-1317

Kit cart - 1190 x 980 mm

This kit cart was custom made for metal frames used to store and transport curtains. The cart is equipped with a handlebar, floor brake, and four nylon casters.

Technical specifications

Category: Kitting Carts

Industry: Automotive, Defense Equipment, Distribution, Industrial Machinery, Tier One Suppliers, Wind & Energy

Length: 47 inch

Width: 39 inch

Load capacity: 1323 lbs

Transportation method: Manual

Caster size: 8 inch

Caster Type: Nylon

Type of Load: Misc parts

More info

This kit cart was custom made for metal frames used to store and transport curtains. The cart is equipped with a handlebar, floor brake and four nylon casters.

Parts included
FlexTube™ 1050 mm 4 Q-000-1053
FlexPlate™ 4 Q-002-1001
Flexplate™ M10 13 Q-002-1162
Wheel Attachment - 105 x 77,5 mm 8 Q-004-1065
Polyamide Caster 200 mm without Brake 4 Q-004-1352
Floor Brake LTL - 200 mm 1 Q-004-1359
Rubber Carpet - 545 x 908 mm 2 Q-005-0452
Spring Threaded Tube Connectors 14 Q-005-0469
Triangle Joint 8 Q-005-0483
Wheel Attachment Box 4 Q-005-1079
Beam to Beam Corner Plate 4 Q-005-1356
64 mm FlexBeam™ Collet 9 Q-005-1426
Lifting eyebolts DIN 580-M10-NI 8 Q-006-0041
Hex Head - M10 x 25 mm 26 Q-006-1041
Locking Nut M10 71 Q-006-1042
Hex Head - M10 x 95 mm 1 Q-006-1088
Hex Head - M10 x 90 mm 1 Q-006-1132
Hex Head - M10 x 30 mm 16 Q-006-1161
Hex Head Fully Threaded - M10 x 50 mm 6 Q-006-1343
Extra Low Head - M10 x 90 mm 7 Q-006-1381
Self Tapping Screw M6 Torx H60 x 16 236 Q-006-1384
Extra Low Head Allen - M10 x 25 mm 14 Q-006-1410
Handle With Bent Top + Floor Brake (North America) 1 Q-015-1060
Angled plate - 1178 mm 2 Q-016-0111
Shelf attachment plate - 980 mm 2 Q-016-0239
Top plate w. edge - 980 x 560 mm 2 Q-016-0682
FlexBeam - 910 mm 8 Q-020-0910
FlexBeam™ - 1120 mm 6 Q-020-1120
FlexBeam™ STS FE - 980 mm 4 Q-021-0980
FlexBeam FE - 1330 mm 4 Q-021-1330
Outer Tube (No Plate) - 627 mm 2 Q-025-0627
Outer Tube (No Plate) - 700 mm 2 Q-025-0700
