Kit Cart - 840 x 1470 mm

Kit cart with shelves, equipped with floor friction brake and polyurethane casters.

Technical specifications

Category: Kitting Carts

Industry: Automotive, Defense Equipment, Distribution, Industrial Machinery, Tier One Suppliers, Wind & Energy

Width: 33 inch

Length: 58 inch

Levels: 5

Load capacity: 399 lbs

Load Capacity per Level: 220 lbs, 51 lbs, 128 lbs

Transportation method: Manual

Caster size: 5 inch

Caster Type: Polyurethane

Type of Load: Bins, Boxes, Misc parts, Totes

More info

This kit cart equipped with flow/flat shelves can be used to move parts, tools and boxes. The shelves have dividers to keep the boxes in place during transportation. The tubes work as handles inside the frame. It is equipped with a floor brake and polyurethane casters.

Parts included
FlexQube 3 Q-001-1078
FlexPlate™ 8 Q-002-1001
Flexplate™ M10 2 Q-002-1162
Flexplate™ 30,5 mm hole 4 Q-002-1320
Floor lock COLSON - 4 x 4-1/2 - 125 - 150 mm 1 Q-004-0031
Caster Polyurathane 125 mm 80 x 60 Swivel 2 Q-004-1220
Caster Polyure. 125 mm 80 x 60 Fixed 2 Q-004-1221
Collet - 35 mm 26 Q-005-0028
Caster to Beam Attachment - 80 x 60 mm 4 Q-005-0265
Floor brake plate 1 Q-005-0275
Spring Threaded Tube Connectors 2 Q-005-0469
Triangle Joint 2 Q-005-0483
Rubber Damper Threaded Stud - 70 x 55 mm 2 Q-005-0743
Beam to Beam Corner Plate 4 Q-005-1356
64 mm FlexBeam™ Collet 20 Q-005-1426
Locking Nut M10 74 Q-006-1042
Hex Head - M8 x 16 mm 36 Q-006-1120
Hex Head - M10 x 90 mm 6 Q-006-1132
Locking Nut M8 52 Q-006-1181
M8 Washer 24 Q-006-1183
M8 x 16 mm Countersunk 16 Q-006-1214
Hex Head Fully Threaded - M10 x 50 mm 20 Q-006-1343
Extra Low Head - M10 x 90 mm 16 Q-006-1381
Self Tapping Screw M6 Torx H60 x 16 80 Q-006-1384
Extra Low Head Allen - M10 x 25 mm 26 Q-006-1410
Hex Head Fully Threaded - M10 x 60 mm 6 Q-006-1502
Outer Tube (No Plate) - 840 mm 1 Q-025-0840
