Kit-Cart with Rollers 840 x 630 mm
Kit-Cart with Rollers 840 x 630 mm
Kit-Cart with Rollers 840 x 630 mm
Kit-Cart with Rollers 840 x 630 mm
Kit-Cart with Rollers 840 x 630 mm
Q-100-0175

Kit-Cart with Rollers 840 x 630 mm

Custom designed kitcart for transporting bins, totes and boxes.

Technical specifications

Transportation method: Manual

Category: Kitting Carts

Industry: Automotive, Commercial Vehicles, Tier One Suppliers

Length: 33 inch

Width: 25 inch

Load capacity: 110 lbs

Caster size: 5 inch

Caster Type: Gray

More info

This custom kit cart is used to improve the presentation of materials to the operators. It comes equipped with one roller shelf for storing loading and unloading components. It is intended to be used alongside Q-100-0176.

Parts included
Outer tube (No plate) - 520 mm 1 Q-000-0072
FlexTube™ 700 mm 2 Q-000-1002
FlexTube™ 560 mm 4 Q-000-1182
FlexTube™ 490 mm 4 Q-000-1247
FlexQube 12 Q-001-1078
FlexBeam™ 770 mm 4 Q-001-1306
FlexPlate™ 16 Q-002-1001
Flexplate™ M10 2 Q-002-1162
Delivery Connector Without Endstop 4 Q-003-1012
Rail Support Drop 30 mm Stop 4 Q-003-1022
125 mm Swivel Caster with Brake 2 Q-004-1364
Fixed Caster - 125 mm 2 Q-004-1365
Handle for 30 mm Tube 2 Q-005-1240
Wheel Attachment - 80 x 60 mm 4 Q-005-1722
Locking Nut M10 2 Q-006-1042
Locking Nut M8 16 Q-006-1181
M8 x 16 mm Countersunk 16 Q-006-1214
Extra low head [1,5 mm] M10x40 mm 2 Q-006-1361
Self Tapping Screw M6 Torx H60 x 16 116 Q-006-1384
Countersunk Self Tapping Screw - M6 x 20 16 Q-006-1385
