Pallet Cart 48 x 40 inch
Pallet Cart 48 x 40 inch
Pallet Cart 48 x 40 inch
Q-100-0264

Pallet Cart 48 x 40 inch

Tuggable flatbed pallet/container cart. The cart comes equipped with a handlebar,floor brake and six polyurethane casters.

Technical specifications

Category: Flat Deck

Industry: Automotive, Defense Equipment, Distribution, Industrial Machinery, Tier One Suppliers, Wind & Energy

Width: 41 inch

Length: 50 inch

Load capacity: 3000 lbs

Transportation method: Manual, Tugger

Caster size: 8 inch

Caster Type: Polyurethane

More info

Tuggable flatbed cart commonly used for the transportation of pallets and containers. The deck gives you the option load the cart with several different pallet/container sizes. The cart is equipped with a handlebar, floor brake and six polyurethane casters, two fixed and four swivel giving you excellent tracking properties and silent movement in a train.

Parts included
FlexBeam™ 1190 mm 8 Q-001-1300
FlexBeam™ 1050 mm FE 2 Q-001-1402
FlexBeam™ 350 mm FE 2 Q-001-1412
FlexPlate™ 4 Q-002-1001
Flexplate™ M10 6 Q-002-1162
Wheel Attachment - 105 x 77,5 mm 2 Q-004-1065
Caster Polyurethane - 200 mm 4 Q-004-1100
Caster Polyurethane 200 mm Fixed 2 Q-004-1101
Floor Brake LTL - 200 mm 1 Q-004-1359
L Bracket Joint 4 Q-005-0031
Wheel Attachment Box - 5 mm 6 Q-005-0046
Spring Cover Plate 1 Q-005-1025
Spring for Tow Bar 2 Q-005-1070
64 mm FlexBeam™ Collet 33 Q-005-1426
Pallet Guide Heavy - 5 mm 4 Q-005-1645
Washer M20 2 Q-006-0016
M10 x 80 mm Countersunk 1 Q-006-0019
Hex Head - M14 x 60 mm 2 Q-006-1036
Locking Nut M14 2 Q-006-1039
Hex Head - M10 x 25 mm 34 Q-006-1041
Locking Nut M10 80 Q-006-1042
Washer M10 26 Q-006-1043
Hex Head - M10 x 95 mm 11 Q-006-1088
Hex Head - M10 x 90 mm 22 Q-006-1132
Hex Head - M10 x 30 mm 4 Q-006-1161
Nut M10 1 Q-006-1195
Hex Head Fully Threaded - M10 x 50 mm 5 Q-006-1343
Self Tapping Screw M6 Torx H60 x 16 74 Q-006-1384
Hex Head Fully Threaded - M10 x 60 mm 2 Q-006-1502
Spring 1,5 x 15yd x 70 1 Q-012-1141
Handlebar / Floor Brake Attachment US 1 Q-015-0029
Handlebar Attachment US 1 Q-015-0031
Tube for Handlebar US 1 Q-015-0032
Bottom Plate - 1260 x 1050 mm 1 Q-016-1076
US Modular Tow Bar VKR - Foot Release - 670 mm 1 Q-017-0012
Cotter Pin - 3,2 x 32 mm 2 Q-017-0023
Foot Release Locking Lip 1 Q-017-0024
Towing lock pin US - 23 mm 1 Q-017-0032
Locking lip attachment 1 Q-017-1043
Tow Bar Lock Tube - 498 mm 1 Q-017-1061
Tow Hole 28 mm - Symmetric 1 Q-017-1066
Tow Attachment to Beam 1 Q-017-1080
Tow Hinge 1 Q-017-1083
39 mm Sleeve for M10 US 2 Q-017-1106
