Q-100-0570

Pallet Cart High 40 x 48 inch

Pallet cart designed with added top structure.

Technical specifications

Category: Standard

Industry: Automotive, Defense Equipment, Distribution, Industrial Machinery, Tier One Suppliers, Wind & Energy

Width: 41 inch

Length: 50 inch

Load capacity: 3000 lbs

Transportation method: Manual

Caster size: 8 inch

Caster Type: Polyurethane

More info

This pallet cart was designed to transport pallets. The purpose of the added top structure is to improve the access to the materials. It presents the pallets at more ergonomic height for the operators. This cart can be equipped with a handlebar and tow bar for easier transportation. It also has four high quality polyamide casters.

Parts included

FlexBeam™ 980 mm 8 Q-001-1303

FlexBeam™ 350 mm 8 Q-001-1312

FlexBeam™ 1120 mm FE 4 Q-001-1401

FlexBeam™ 1260 mm FE 4 Q-001-1500

FlexPlate™ 4 Q-002-1001

Wheel Attachment - 105 x 77,5 mm 4 Q-004-1065

Polyamide Caster 200 mm with Brake 4 Q-004-1351

Beam Pallet Guide 4 Q-005-0384

Beam to Beam Corner Plate 4 Q-005-1356

64 mm FlexBeam™ Collet 40 Q-005-1426

Locking Nut M10 64 Q-006-1042

Hex Head - M10 x 90 mm 16 Q-006-1132

Extra Low Head - M10 x 90 mm 40 Q-006-1381

Self Tapping Screw M6 Torx H60 x 16 112 Q-006-1384

Extra Low Head Allen - M10 x 25 mm 8 Q-006-1410
