Q-100-0796

Push Cart - 1260 x 1190 mm

Basic push cart designed for transporting pallets and containers.

Technical specifications

Category: Standard

Industry: Automotive, Defense Equipment, Distribution, Industrial Machinery, Tier One Suppliers, Wind & Energy

Width: 47 inch

Length: 50 inch

Load capacity: 1499 lbs

Transportation method: Manual

Caster size: 8 inch

Caster Type: Nylon

Type of Load: Pallets and Containers

More info

This basic push cart is designed for transporting pallet and containers. It comes equipped with a floor lock brake to keep the cart secure when not in use. A tow bar and steel flat deck can be easily added to this cart.

Parts included

FlexBeam™ 1120 mm 6 Q-001-1301

FlexBeam™ 1260 mm FE 2 Q-001-1500

FlexPlate™ 8 Q-002-1001

Polyamide Caster 200 mm without Brake 2 Q-004-1352

Polyamide Caster 200 mm Fixed 2 Q-004-1354

US Floor Brake - 200 mm 1 Q-004-1613

Wheel Attachment Box 4 Q-005-1079

Pallet Guide Corner Plate 4 Q-005-1096

Floor Brake Plate 1 Q-005-1387

64 mm FlexBeam™ Collet 12 Q-005-1426

Hex Head - M10 x 25 mm 32 Q-006-1041

Locking Nut M10 54 Q-006-1042

Washer M10 4 Q-006-1043

Hex Head - M10 x 90 mm 8 Q-006-1132

Extra Low Head - M10 x 90 mm 8 Q-006-1381

Self Tapping Screw M6 Torx H60 x 16 28 Q-006-1384

Extra Low Head Allen - M10 x 25 mm 12 Q-006-1410
