Sub Frame 2380 x 1050 mm
Sub Frame 2380 x 1050 mm
Sub Frame 2380 x 1050 mm
Sub Frame 2380 x 1050 mm
Q-007-1914

Sub Frame 2380 x 1050 mm

Large sub-frame designed for pallet carts.

Technical specifications

Category: Standard

Industry: Automotive, Defense Equipment, Distribution, Industrial Machinery, Tier One Suppliers, Wind & Energy

Length: 94 inch

Load capacity: 2205 lbs

Width: 41 inch

Transportation method: Manual

More info

This sub frame was ordered to go along with many pallet trolleys. These sub frames help to create a better ergonomic height for the operators when accessing the materials. One of the pallet carts that were ordered to go along with these sub frames is Q-007-1111.

Parts included
FlexTube™ 70 mm - Locking Nut 8 Q-000-1101
FlexBeam™ - 1610 mm 4 Q-001-1294
FlexBeam™ 700 mm 4 Q-001-1307
FlexBeam™ 1050 mm FE 2 Q-001-1402
FlexPlate™ 8 Q-002-1001
Pallet Guide Corner Plate 4 Q-005-1096
64 mm FlexBeam™ Collet 8 Q-005-1426
Locking Nut M10 16 Q-006-1042
Extra Low Head - M10 x 90 mm 8 Q-006-1381
Self Tapping Screw M6 Torx H60 x 16 64 Q-006-1384
Extra Low Head Allen - M10 x 25 mm 8 Q-006-1410
