Tugger Cart - 1260 x 1050 mm
Tugger Cart - 1260 x 1050 mm
Tugger Cart - 1260 x 1050 mm
Tugger Cart - 1260 x 1050 mm
Q-100-0964

Tugger Cart - 1260 x 1050 mm

Simple tugger cart designed for transporting containers and boxes.

Technical specifications

Category: Flat Deck

Industry: Automotive, Defense Equipment, Distribution, Industrial Machinery, Tier One Suppliers, Wind & Energy

Type of tow bar: Tongue and Hitch

Width: 41 inch

Length: 50 inch

Load capacity: 2205 lbs

Transportation method: Manual, Tugger

Caster size: 8 inch

Caster Type: Polyurethane

Type of Load: Bins, Boxes

More info

This flatbed cart is ideal for transporting different sized containers, bins and boxes. It comes equipped with a drop pin and hitch tow bar for transportation using a tugger train system. It also comes equipped with a floor lock brake to secure the cart when not in use.

Parts included
FlexBeam™ 1190 mm 4 Q-001-1300
FlexBeam™ 1120 mm FE 2 Q-001-1401
FlexBeam™ 1050 mm FE 2 Q-001-1402
FlexBeam™ 910 mm FE 2 Q-001-1404
Flexplate™ M10 13 Q-002-1162
Wheel Attachment - 105 x 77,5 mm 2 Q-004-1065
Caster Polyurethane - 200 mm 4 Q-004-1100
Caster Polyurethane 200 mm Fixed 2 Q-004-1101
US Floor Brake - 200 mm 1 Q-004-1613
163 mm Collet - 30 x 2 mm 1 Q-005-0298
184 mm Collet - 25 x 2 mm 1 Q-005-0299
Spring tow bar 1 Q-005-0450
M8 Damper - GN352-30-25-M8-S-55 2 Q-005-0648
Towing Hole 2 Q-005-1056
Wheel Attachment Box 6 Q-005-1079
Pallet Guide Corner Plate 4 Q-005-1096
64 mm FlexBeam™ Collet 24 Q-005-1426
Allen Head - M6 x 30 mm 1 Q-006-1012
Washer 10,5 x 30 x 2,5 2 Q-006-1030
Hex Head - M14 x 60 mm 2 Q-006-1036
Locking Nut M14 2 Q-006-1039
Hex Head - M10 x 25 mm 36 Q-006-1041
Locking Nut M10 83 Q-006-1042
Washer M10 18 Q-006-1043
Locking Nut M6 1 Q-006-1050
Hex Head - M10 x 95 mm 4 Q-006-1088
Hex Head - M10 x 90 mm 17 Q-006-1132
Hex Head - M10 x 30 mm 6 Q-006-1161
Locking Nut M8 2 Q-006-1181
Hex head M20 x 210 mm 1 Q-006-1364
Extra Low Head - M10 x 90 mm 13 Q-006-1381
Countersunk Self Tapping Screw - M6 x 20 52 Q-006-1385
M20 Locking Nut 1 Q-006-1405
Extra Low Head Allen - M10 x 25 mm 4 Q-006-1410
Hex Head Fully Threaded - M10 x 60 mm 3 Q-006-1502
Compression Spring for US Tow Hitch 1 Q-012-0007
Handle With Bent Top + Floor Brake (North America) 1 Q-015-1060
Top plate - 1050 x 1260 mm 1 Q-016-0331
US Modular Tow Bar VKR - Lip - 380 mm 1 Q-017-0015
Handle for Tow Hole 1 Q-017-0022
Hinge attachment 1 Q-017-0035
Towbar Hinge 1 Q-017-0036
Towing Lip - 28 mm 1 Q-017-1010
