Tugger Cart - 1610 x 1260 mm
Tugger Cart - 1610 x 1260 mm
Tugger Cart - 1610 x 1260 mm
Q-007-3091

Tugger Cart - 1610 x 1260 mm

Standard tugger cart without steel flat deck.

Technical specifications

Category: Standard

Industry: Automotive, Defense Equipment, Distribution, Industrial Machinery, Tier One Suppliers, Wind & Energy

Width: 50 inch

Length: 63 inch

Load capacity: 1653 lbs

Transportation method: Manual, Tugger

Caster size: 5 inch

Caster Type: Polyurethane

More info

This tugger cart was designed to transport pallets and containers. It comes equipped with an ergonomic handlebar for easier manual transportation. There is also a wire release tow bar for transportation via tugger train. The purpose of the wire release is to improve ergonomics and reduce bending/flexing by the operators.

Parts included
FlexBeam™ - 1540 mm 4 Q-001-1295
FlexBeam™ 1120 mm FE 2 Q-001-1401
FlexBeam™ 1260 mm FE 2 Q-001-1500
FlexBeam™ - 1470 mm FE 2 Q-001-1503
FlexPlate™ 8 Q-002-1001
Flexplate™ M10 12 Q-002-1162
Caster Polyurethane - 125 mm 4 Q-004-1106
Caster Polyurethane 125 mm Fixed 2 Q-004-1107
Floor Brake LTL - 125 mm 1 Q-004-1360
Floor brake plate 1 Q-005-0275
Collet - 31 mm 2 Q-005-1008
Old part: Spring for Tow Bar 2 Q-005-1012
Damper GN352 1 Q-005-1016
Spring Cover Plate 1 Q-005-1025
Wire Guidance Plate 1 Q-005-1026
Wheel Attachment Box 6 Q-005-1079
Angled Corner Plate 4 Q-005-1098
64 mm FlexBeam™ Collet 24 Q-005-1426
Hex Head - M20 x 500 mm 1 Q-006-1016
Hex Head - M4 x 8 mm 1 Q-006-1028
Hex Head - M10 x 25 mm 13 Q-006-1041
Locking Nut M10 79 Q-006-1042
Washer M10 72 Q-006-1043
Scissor Sprint 2,5 x 16 FZB 1 Q-006-1077
Hex Head - M10 x 95 mm 7 Q-006-1088
Countersunk - M10 x 70 mm 1 Q-006-1112
Hex Head - M10 x 90 mm 10 Q-006-1132
Hex Head - M10 x 30 mm 4 Q-006-1161
Hex Head Fully Threaded - M10 x 50 mm 2 Q-006-1343
Extra Low Head - M10 x 90 mm 15 Q-006-1381
Self Tapping Screw M6 Torx H60 x 16 40 Q-006-1384
M20 Locking Nut 1 Q-006-1405
Extra Low Head Allen - M10 x 25 mm 27 Q-006-1410
Hex Head Fully Threaded - M10 x 60 mm 1 Q-006-1502
Spring 1,5 x 15yd x 70 1 Q-012-1141
Floor Brake Handle (Europe) 1 Q-015-1052
Countersunk Towing Lock Pin - 25 mm 1 Q-017-0010
Towing Equipment - Locking Lip 1 Q-017-1015
Towing - Spring attachment 1 Q-017-1016
Locking lip attachment 1 Q-017-1043
Trigger Handle 1 Q-017-1050
Rubber Bushing 498030 1 Q-017-1062
Tow Hole 28 mm - Symmetric 1 Q-017-1066
Tow Attachment to Beam 1 Q-017-1080
