Tugger Cart -1610 x 3710 mm
Tugger Cart -1610 x 3710 mm
Tugger Cart -1610 x 3710 mm
Tugger Cart -1610 x 3710 mm
Q-100-1470

Tugger Cart -1610 x 3710 mm

Tugger flatbed pallet cart equipped with a floor brake and six polyurethane casters.

Technical specifications

Category: Flat Deck

Industry: Automotive, Defense Equipment, Distribution, Industrial Machinery, Tier One Suppliers, Wind & Energy

Type of tow bar: Tongue and Hitch

Width: 63 inch

Length: 146 inch

Load capacity: 2998 lbs

Transportation method: Manual, Tugger

Caster size: 8 inch

Caster Type: Polyurethane

More info

Flatbed pallet cart used the transportation of larger pallets and containers or several smaller. The cart is equipped with a tow bar and a floor brake as well as six high quality polyurethane casters, two fixed and four swivel giving the cart excellent tracking properties and silent movement when connected in a train.

Parts included
FlexBeam™ - 1470 mm 8 Q-001-1296
FlexBeam™ 700 mm 4 Q-001-1307
FlexBeam™ - 1470 mm FE 10 Q-001-1503
FlexBeam™ - 1610 mm FE 2 Q-001-1505
FlexPlate™ 18 Q-002-1001
Flexplate™ M10 16 Q-002-1162
Wheel Attachment - 105 x 77,5 mm 2 Q-004-1065
Caster Polyurethane 200 mm with Brake 4 Q-004-1099
Caster Polyurethan 200 mm Fixed IP2 2 Q-004-1212
Wheel Attachment Box - 5 mm 9 Q-005-0046
Angle corner plate - 5 mm 4 Q-005-0227
Reinforcement Plate - 770 mm 4 Q-005-1112
Triangle Corner Plate 8 Q-005-1145
64 mm FlexBeam™ Collet 58 Q-005-1426
Hex Head - M14 x 60 mm 4 Q-006-1036
Locking Nut M14 4 Q-006-1039
Hex Head - M10 x 25 mm 36 Q-006-1041
Locking Nut M10 144 Q-006-1042
Hex Head - M10 x 95 mm 14 Q-006-1088
Hex Head - M10 x 90 mm 58 Q-006-1132
Countersunk MF6S - M10 x 90 mm 24 Q-006-1135
Extra Low Head - M10 x 90 mm 8 Q-006-1381
Self Tapping Screw M6 Torx H60 x 16 232 Q-006-1384
Extra Low Head Allen - M10 x 25 mm 4 Q-006-1410
US Modular Tow Bar VKR - LIP - 520 mm 1 Q-017-0014
Spring Loaded Tow Hinge 1 Q-017-0067
Heavy Duty Tow Hinge - Narrow 1 Q-017-0087
Towing Lip - 2,5 Inch 1 Q-017-1012
