Tugger Cart - 1680 x 1260 mm
Tugger Cart - 1680 x 1260 mm
Tugger Cart - 1680 x 1260 mm
Tugger Cart - 1680 x 1260 mm
Q-100-0860

Tugger Cart - 1680 x 1260 mm

Tugger flatbed pallet cart equipped with a handlebar, floor brake, and six polyurethane casters.

Technical specifications

Category: Flat Deck

Industry: Automotive, Defense Equipment, Distribution, Industrial Machinery, Tier One Suppliers, Wind & Energy

Width: 50 inch

Length: 66 inch

Load capacity: 2205 lbs

Transportation method: Manual, Tugger

Caster size: 5 inch

Caster Type: Polyurethane

Type of Load: Pallets and Containers

More info

This flatbed pallet cart is great for transportation of larger pallets and containers or several smaller. The cart is equipped with a tow bar, handlebar, floor brake as well as six high quality polyurethane casters which gives the cart excellent tracking properties and silent movement when connected to a train

Parts included
FlexBeam™ - 1610 mm 4 Q-001-1294
FlexBeam™ 1120 mm FE 2 Q-001-1401
FlexBeam™ 1260 mm FE 2 Q-001-1500
FlexBeam™ 1540 mm FE 2 Q-001-1504
FlexPlate™ 8 Q-002-1001
Flexplate™ M10 12 Q-002-1162
Wheel Attachment - 105 x 77,5 mm 2 Q-004-1065
Caster Polyurethane - 200 mm 4 Q-004-1100
Caster Polyurethane 200 mm Fixed 2 Q-004-1101
Floor Brake LTL - 200 mm 1 Q-004-1359
M8 Damper - GN352-30-25-M8-S-55 1 Q-005-0648
Collet - 31 mm 2 Q-005-1008
Spring Cover Plate 1 Q-005-1025
Wheel Attachment Box 6 Q-005-1079
Pallet Guide Corner Plate 4 Q-005-1096
64 mm FlexBeam™ Collet 24 Q-005-1426
Washer 10,5 x 30 x 2,5 1 Q-006-1030
Hex Head - M10 x 25 mm 44 Q-006-1041
Locking Nut M10 90 Q-006-1042
Washer M10 2 Q-006-1043
Hex Head - M10 x 95 mm 4 Q-006-1088
Countersunk - M10 x 70 mm 1 Q-006-1112
Hex Head - M10 x 90 mm 16 Q-006-1132
Locking Nut M8 1 Q-006-1181
Hex Head Fully Threaded - M10 x 50 mm 5 Q-006-1343
Extra Low Head - M10 x 90 mm 16 Q-006-1381
Self Tapping Screw M6 Torx H60 x 16 108 Q-006-1384
Extra Low Head Allen - M10 x 25 mm 4 Q-006-1410
Spring 1,5 x 15yd x 70 1 Q-012-1141
Handlebar Attachment EUR 1 Q-015-0026
Handlebar / Floor brake attachment EUR 1 Q-015-0027
Tube for Handlebar EUR 1 Q-015-0033
Top Plate - 1260 x 840 mm 2 Q-016-0413
Countersunk Towing Lock Pin - 25 mm 1 Q-017-0010
Foot Release Locking Lip 1 Q-017-0024
Tow Hinge Module 1 Q-017-0059
Tow Hole 28 mm - Symmetric 1 Q-017-1066
