Tugger Cart 2520 x 1260 mm
Tugger Cart 2520 x 1260 mm
Tugger Cart 2520 x 1260 mm
Tugger Cart 2520 x 1260 mm
Q-100-0613

Tugger Cart 2520 x 1260 mm

Custom-designed tugger cart with added tubes for easier handling.

Technical specifications

Category: Flat Deck

Industry: Automotive, Defense Equipment, Distribution, Industrial Machinery, Tier One Suppliers, Wind & Energy

Type of tow bar: Tongue and Hitch

Width: 50 inch

Length: 99 inch

Load capacity: 2000 lbs

Transportation method: Tugger

Caster size: 5 inch

Caster Type: Polyurethane

More info

This custom tugger cart was designed to transport long and large materials. But this cart can also be used for transporting pallets and containers. The tubes are attached to the top structure to make the cart easier to handle. It also comes with a drop pin and hitch tow bar for transportation via tugger train.

Parts included
FlexTube™ Inner 700 mm 12 Q-000-1004
FlexBeam™ 1050 mm 4 Q-001-1302
FlexBeam™ 770 mm 4 Q-001-1306
FlexBeam™ 630 mm 4 Q-001-1308
FlexBeam™ 1120 mm FE 6 Q-001-1401
FlexBeam™ 1260 mm FE 2 Q-001-1500
FlexPlate™ 16 Q-002-1001
Stiffener - Outside 4 Q-002-1050
Flexplate™ M10 8 Q-002-1162
Floor lock COLSON - 4 x 4-1/2 - 125 - 150 mm 1 Q-004-0031
Caster distance plate - 5 mm 4 Q-004-0038
Caster Polyurethane - 125 mm 4 Q-004-1106
Caster Polyurethane 125 mm Fixed 2 Q-004-1107
Towing Hole 2 Q-005-1056
Spring for Tow Bar 2 Q-005-1070
Wheel Attachment Box 6 Q-005-1079
Reinforcement Plate - 770 mm 2 Q-005-1112
Triangle Corner Plate 4 Q-005-1145
Floor brake handle - wheel plate 1 Q-005-1383
Caster Distance Collet - 18 mm 4 Q-005-1396
64 mm FlexBeam™ Collet 12 Q-005-1426
Allen Head - M6 x 30 mm 1 Q-006-1012
Hex Head - M20 x 500 mm 1 Q-006-1016
Hex Head - M14 x 60 mm 4 Q-006-1036
Locking Nut M14 4 Q-006-1039
Hex Head - M10 x 25 mm 20 Q-006-1041
Locking Nut M10 94 Q-006-1042
Washer M10 24 Q-006-1043
Locking Nut M6 1 Q-006-1050
Hex Head - M10 x 95 mm 1 Q-006-1088
Hex Head - M10 x 90 mm 18 Q-006-1132
Countersunk MF6S - M10 x 90 mm 12 Q-006-1135
Hex Head - M10 x 30 mm 2 Q-006-1161
Nut M10 1 Q-006-1195
Hex Head - M10 x 40 4 Q-006-1208
Hex Head Fully Threaded - M10 x 50 mm 1 Q-006-1343
Extra Low Head - M10 x 90 mm 8 Q-006-1381
Self Tapping Screw M6 Torx H60 x 16 160 Q-006-1384
Countersunk Self Tapping Screw - M6 x 20 56 Q-006-1385
M20 Locking Nut 1 Q-006-1405
Extra Low Head Allen - M10 x 25 mm 28 Q-006-1410
Compression Spring for US Tow Hitch 1 Q-012-0007
US Modular Tow Bar VKR - LIP - 520 mm 1 Q-017-0014
Handle for Tow Hole 1 Q-017-0022
Towing Lip - 28 mm 1 Q-017-1010
Tow Attachment to Beam 1 Q-017-1080
Tow Hinge 1 Q-017-1083
