Tugger Cart – 700 x 840 mm
Tugger Cart - 32 x 30 Inch (Without top-plate)
Tugger Cart - 32 x 30 Inch (Without top-plate)
Tugger Cart - 32 x 30 Inch (Without top-plate)
Q-100-0569

Tugger Cart – 700 x 840 mm

Small tugger cart designed without steel flat deck.

Technical specifications

Category: Standard

Industry: Automotive, Defense Equipment, Distribution, Industrial Machinery, Tier One Suppliers, Wind & Energy

Type of tow bar: Tongue and Hitch

Width: 28 inch

Length: 33 inch

Load capacity: 1653 lbs

Transportation method: Manual, Tugger

Caster size: 8 inch

Caster Type: Polyurethane

Type of Load: Bins, Boxes

More info

This smaller tugger cart was designed for transporting containers, but can also be used for transporting bins and boxes. It comes with an ergonomic handlebar for easier manual transportation. It also has a drop pin and hitch tow bar for transportation via a tugger train system.

Parts included
FlexBeam™ 770 mm 4 Q-001-1306
FlexBeam™ 770 mm FE 2 Q-001-1406
FlexBeam™ 630 mm FE 2 Q-001-1408
FlexPlate™ 4 Q-002-1001
Caster Polyurethane - 200 mm 2 Q-004-1100
Caster Polyurethane 200 mm Fixed 2 Q-004-1101
Floor Brake LTL - 200 mm 1 Q-004-1359
Angle corner plate - 5 mm 2 Q-005-0227
Towing Hole 2 Q-005-1056
Spring for Tow Bar 2 Q-005-1070
Wheel Attachment Box 4 Q-005-1079
Left Angle Corner Plate 1 Q-005-1097
Right Angle Corner Plate 1 Q-005-1099
64 mm FlexBeam™ Collet 12 Q-005-1426
Allen Head - M6 x 30 mm 1 Q-006-1012
Hex Head - M20 x 500 mm 1 Q-006-1016
Hex Head - M14 x 60 mm 4 Q-006-1036
Locking Nut M14 4 Q-006-1039
Hex Head - M10 x 25 mm 26 Q-006-1041
Locking Nut M10 59 Q-006-1042
Washer M10 8 Q-006-1043
Locking Nut M6 1 Q-006-1050
Hex Head - M10 x 95 mm 2 Q-006-1088
Hex Head - M10 x 90 mm 8 Q-006-1132
Hex Head - M10 x 30 mm 6 Q-006-1161
Nut M10 1 Q-006-1195
Hex Head Fully Threaded - M10 x 50 mm 1 Q-006-1343
Extra Low Head - M10 x 90 mm 4 Q-006-1381
Self Tapping Screw M6 Torx H60 x 16 16 Q-006-1384
M20 Locking Nut 1 Q-006-1405
Extra Low Head Allen - M10 x 25 mm 12 Q-006-1410
Compression Spring for US Tow Hitch 1 Q-012-0007
Handle With Bent Top + Floor Brake (North America) 1 Q-015-1060
US Modular Tow Bar VKR - Lip - 380 mm 1 Q-017-0015
Handle for Tow Hole 1 Q-017-0022
Towing Lip - 28 mm 1 Q-017-1010
Tow Attachment to Beam 1 Q-017-1080
Tow Hinge 1 Q-017-1083
