Tugger Cart - 560 x 1050 mm
Tugger Cart - 560 x 1050 mm
Tugger Cart - 560 x 1050 mm
Tugger Cart - 560 x 1050 mm
Q-100-1566

Tugger Cart - 560 x 1050 mm

Tugger cart with platform at a higher position.

Technical specifications

Category: Flat Deck

Industry: Automotive, Defense Equipment, Distribution, Industrial Machinery, Tier One Suppliers, Wind & Energy

Type of tow bar: Tongue and Hitch

Width: 25 inch

Length: 44 inch

Load capacity: 1543 lbs

Transportation method: Manual, Tugger

Caster size: 5 inch

Caster Type: Gray

More info

This tugger cart is perfect when the platform is required to be in a higher position. The FlexTubes placed between the base frame and the top frame allow the desired height. The cart has a steel deck, drop pin tow bar and 125 mm diameter Polyrurethane casters.

Parts included
FlexTube™ 210 mm 4 Q-000-1224
FlexPlate™ 8 Q-002-1001
Stiffener - Outside 4 Q-002-1050
Flexplate™ M10 4 Q-002-1162
Caster Polyure. 125 mm 80 x 60 Fixed 2 Q-004-1221
Caster to Beam Attachment - 80 x 60 mm 4 Q-005-0265
Spring Threaded Tube Connectors 12 Q-005-0469
Pallet Guide Corner Plate 4 Q-005-1096
64 mm FlexBeam™ Collet 32 Q-005-1426
Hex Head - M14 x 60 mm 4 Q-006-1036
Locking Nut M14 4 Q-006-1039
Locking Nut M10 44 Q-006-1042
Hex Head - M10 x 90 mm 10 Q-006-1132
Locking Nut M8 16 Q-006-1181
M8 x 16 mm Countersunk 16 Q-006-1214
Extra low head [1,5 mm] M10x40 mm 4 Q-006-1361
Extra Low Head - M10 x 90 mm 24 Q-006-1381
Self Tapping Screw M6 Torx H60 x 16 104 Q-006-1384
Low Allen Head - M10 x 16 mm 2 Q-006-1409
Extra Low Head Allen - M10 x 25 mm 12 Q-006-1410
Top Plate - 560 x 1050 mm 1 Q-016-0419
US Modular Tow Bar VKR - Lip - 380 mm 1 Q-017-0015
Spring Loaded Tow Hinge 1 Q-017-0067
Heavy Duty Tow Hinge - Narrow 1 Q-017-0087
Towing Lip - 28 mm 1 Q-017-1010
FlexBeam™ - 980 mm 8 Q-020-0980
FlexBeam™ FE - 420 mm 4 Q-021-0420
FlexBeam™ FE - 560 mm 4 Q-021-0560
Outer Tube (No Plate) - 350 mm 4 Q-025-0350
