Tugger Cart - 66 x 50 inch
Tugger Cart - 66 x 50 inch
Tugger Cart - 66 x 50 inch
Tugger Cart - 66 x 50 inch
Tugger Cart - 66 x 50 inch
Tugger Cart - 66 x 50 inch
Tugger Cart - 66 x 50 inch
Q-100-0066

Tugger Cart - 66 x 50 inch

Simply designed tugger cart without flat deck for transporting pallets and containers.

Technical specifications

Category: Standard

Industry: Automotive, Defense Equipment, Distribution, Industrial Machinery, Tier One Suppliers, Wind & Energy

Width: 50 inch

Length: 66 inch

Load capacity: 992 lbs

Type of tow bar: Tongue and Hitch

Transportation method: Manual, Tugger

Caster size: 5 inch

Caster Type: Polyurethane

More info

This tugger cart doesn’t have a flat deck and is used for transporting containers. This cart also comes with an attached ergonomic handlebar for easier manual transportation. It also comes with a drop pin and hitch tow bar for use with a tugger train system. This cart comes with six high quality polyamide casters.

Parts included
FlexBeam™ - 1610 mm 6 Q-001-1294
FlexBeam™ 1260 mm FE 2 Q-001-1500
FlexPlate™ 22 Q-002-1001
Flexplate™ M10 1 Q-002-1162
125 mm Swivel Caster with Brake 4 Q-004-1364
Fixed Caster - 125 mm 2 Q-004-1365
Floor Lock COLSON 4 x 4-1/2 1 Q-004-1369
M8 Damper - GN352-30-25-M8-S-55 1 Q-005-0648
Towing Hole 2 Q-005-1056
Pallet Guide Corner Plate 4 Q-005-1096
64 mm FlexBeam™ Collet 12 Q-005-1426
Heavy Duty Joint M10 2 Q-005-1580
Corner Pallet Guide 4 Q-005-1684
Wheel Attachment - 80 x 60 mm 6 Q-005-1722
Allen Head - M6 x 30 mm 1 Q-006-1012
Washer 10,5 x 30 x 2,5 1 Q-006-1030
Hex Head - M14 x 60 mm 2 Q-006-1036
Locking Nut M14 2 Q-006-1039
Hex Head - M10 x 25 mm 8 Q-006-1041
Locking Nut M10 41 Q-006-1042
Washer M10 2 Q-006-1043
Locking Nut M6 1 Q-006-1050
Hex Head - M10 x 30 mm 2 Q-006-1161
Locking Nut M8 25 Q-006-1181
Hex Head - M10 x 40 4 Q-006-1208
M8 x 16 mm Countersunk 24 Q-006-1214
Extra Low Head - M10 x 90 mm 12 Q-006-1381
Self Tapping Screw M6 Torx H60 x 16 72 Q-006-1384
Countersunk Self Tapping Screw - M6 x 20 24 Q-006-1385
Extra Low Head Allen - M10 x 25 mm 12 Q-006-1410
Hex Head Fully Threaded - M10 x 60 mm 3 Q-006-1502
Compression Spring for US Tow Hitch 1 Q-012-0007
Handle With Bent Top + Floor Brake (North America) 1 Q-015-1060
US Modular Tow Bar VKR - LIP - 520 mm 1 Q-017-0014
Handle for Tow Hole 1 Q-017-0022
Tow Hinge Module 1 Q-017-0059
Towing Lip - 28 mm 1 Q-017-1010
Collet - 11.5 mm 4 Q-015-1048
