Tugger Cart - 840 x 1260 mm
Tugger Cart - 840 x 1260 mm
Tugger Cart - 840 x 1260 mm
Tugger Cart - 840 x 1260 mm
Q-100-1330

Tugger Cart - 840 x 1260 mm

This tugger cart is designed to transport pallets and containers in a tugger train.

Technical specifications

Category: Standard

Industry: Automotive, Defense Equipment, Distribution, Industrial Machinery, Tier One Suppliers, Wind & Energy

Type of tow bar: Tongue and Hitch

Width: 33 inch

Length: 50 inch

Load capacity: 1102 lbs

Transportation method: Tugger

Caster size: 5 inch

Caster Type: Polyurethane

More info

This cart is designed to carry heavy-duty pallets and containers. It is equipped with a drop-pin and hitch towbar and six high-quality polyurethane casters which give the cart excellent tracking properties and silent movement when connected in a train. Also, the cart uses a floor friction brake and corner pallet guides to help to place the containers or pallets on the frame.

Parts included
FlexPlate™ 8 Q-002-1001
Caster Polyurathane 125 mm 80 x 60 Swivel 4 Q-004-1220
Caster Polyure. 125 mm 80 x 60 Fixed 2 Q-004-1221
Floor Lock COLSON 4 x 4-1/2 1 Q-004-1369
Caster to Beam Attachment - 80 x 60 mm 6 Q-005-0265
Angled Corner Plate 4 Q-005-1098
Floor Brake Plate 1 Q-005-1387
64 mm FlexBeam™ Collet 24 Q-005-1426
Wheel Attachment - 80 x 60 mm 2 Q-005-1722
Hex Head - M14 x 60 mm 4 Q-006-1036
Locking Nut M14 4 Q-006-1039
Locking Nut M10 36 Q-006-1042
Washer M10 12 Q-006-1043
Hex Head - M10 x 90 mm 11 Q-006-1132
Hex Head - M10 x 30 mm 5 Q-006-1161
Locking Nut M8 24 Q-006-1181
M8 x 16 mm Countersunk 16 Q-006-1214
Countersunk - M8 x 20 8 Q-006-1282
Extra Low Head - M10 x 90 mm 15 Q-006-1381
Self Tapping Screw M6 Torx H60 x 16 32 Q-006-1384
Low Allen Head - M10 x 16 mm 2 Q-006-1409
Extra Low Head Allen - M10 x 25 mm 3 Q-006-1410
US Modular Tow Bar VKR - Lip - 380 mm 1 Q-017-0015
Spring Loaded Tow Hinge 1 Q-017-0067
Heavy Duty Tow Hinge - Narrow 1 Q-017-0087
Towing Lip - 28 mm 1 Q-017-1010
FlexBeam™ - 1190 mm 4 Q-020-1190
